IBANEZ GRG121SP GYC CHITARRA ELETTRICA

SPECS
neck type GRGRoasted Maple neck
top/back/body Poplar body
fretboard Jatoba fretboardWhite dot inlay
fret Medium frets
number of frets 24
bridge F106 bridge
string space 10.5mm
neck pickup Classic Elite (H) neck pickupPassive/Ceramic
bridge pickup Classic Elite (H) bridge pickupPassive/Ceramic
factory tuning 1E,2B,3G,4D,5A,6E
string gauge .010/.013/.017/.026/.036/.046
hardware color Chrome
NECK DIMENSIONS
Scale : 648mm/25.5"
a : Width 43mm at NUT
b : Width 58mm at 24F
c : Thickness 19.5mm at 1F
d : Thickness 21.5mm at 12F
Radius : 400mmR
DESCRIPTION
Guitar Neck Diagram
a: Width of the neck at the nut
b: Width of the neck at the fret position specified by the neck dimension
c: Thickness of the neck at the first fret
d: Thickness of the neck at the fret position specified by the neck dimension
Radius: Radius of the fingerboard
